| Modle: |
COMPTON-600 Lay-in Ceilings system |
|
|
|
|
| description: |
COMPTON 600 groove frame broken decades old design is very popular in the building market.
COMPTON has widely been recognized as a key point in setting office environment contributing to its simplicity and modernization.
COMPTON designers thought successful ceiling design can give inspiration to a company manager, an important person in planning the company future, who may hardly get into the best working mood when facing “a blank ceiling “ , so COMPTON has been designed in this way.
|
| Keel: |
41mm high, 14.3mm wide, 0.4mm thick, coating material for hot-dip galvanizing made available in black, white groove. |
| Panel: |
Thickness of 0.7mm, width of 600mm, length 600mm, material for aluminum alloy 3003, spraying the surface with powder. |
| Color: |
The color can be chosen with reference to the color swatch cards Compton offers. |
| Suspension rod system: |
φ 6mm screw rod. |
| Perforation: |
φ 2.3mm (with Germany Soundtex sound muffling non-woven fabrics on the back). |
| Integrated system: |
It is proposed that the lighting and air-conditioning should be at the same level of ceiling, or the lighting be installed under the ceiling separately. |
| Minimum clearance: |
250mm |
| Interval of keel: |
perforation or plain tile is available |
| Interval of the suspension rod: |
1200mm x 1200mm |
|
|
|
